Color TFT Display Coating Thickness Tester With Adjustable Backlight MT600

Mitech CO.,LTD.

Color TFT Display Coating Thickness Tester With Adjustable Backlight MT600

Brand Name : MITECH

Model Number : MT600

Certification : CE / GOST

Place of Origin : China Beijing

MOQ : 1 piece

Payment Terms : Western Union, T/T, Paypal

Supply Ability : 500 Unit/Units per Month

Delivery Time : after receiving payment

Packaging Details : Standard export carton

Measuring range : 0.65-600mm(P-E),3-100mm(E-E)

Communication : USB. Bluetooth

Working time : 30h (default brightness setting)

Memory : 100 groups (100values for each group) of stored values

Power supply : Two “AA” size, 1.5 Volt alkaline batteries

Dimensions : 150mm×76mm×38mm

Resolution : 0.1/0.01/0.001mm

Contact Now

MT600 Multi-mode Ultrasonic Thickness Gauge with good quality and best price for a better experience

Product Overview

The model MT600 is a multi-mode ultrasonic thickness gauge. Based on the same operating principles as SONAR, the instrument is capable of measuring the thickness of various materials with accuracy as high as 0.1/0.01/0.001 millimeters.

The multi-mode feature of the gauge allows the user to toggle between pulse-echo mode (flaw and pit detection), and echo-echo mode (eliminate paint or coating thickness).

Product Features

  • Multi-mode: Pulse-Echo mode (P-E mode) and Echo-Echo mode (E-E mode). In Echo-Echo mode, it can test the wall thickness eliminating paint or coating thickness.
  • Wide measuring range:Pulse-Echo mode: (0.65~600)mm (in Steel). Echo-Echo mode: (3~100)mm
  • V-Path correction to compensate the nonlinearity of the probe
  • Color TFT display (320×240 TFT LCD) with adjustable backlight, allow the user to work at worksites with low visibility.
  • Non-volatile memory can store 100 groups of test thickness. One hundred records max for each group.
  • Two AA size alkaline batteries as the power source. Continuous operating period of no less than 100 hours (default brightness setting). Display Standby and Auto Power Off functions to save power.
  • With internal Bluetooth module, it can print test report wirelessly.
  • USB 2.0 communication port. Online transfer of the measured data to PC via USB.

Measuring Principle

The ultrasonic thickness gauge determines the thickness of a part or structure by accurately measuring the time required for a short ultrasonic pulse generated by a transducer to travel through the thickness of the material, reflect from the back or inside surface, and be returned to the transducer. The measured two-way transit time is divided by two to account for the down-and-back travel path, and then multiplied by the velocity of sound in the material. The result is expressed in the well-known relationship:

Color TFT Display Coating Thickness Tester With Adjustable Backlight MT600

Where:H-Thickness of the test piece.

v-Sound Velocity in the material.

t-The measured round-trip transit time.

Specifications

  • Multi-mode: Pulse-Echo mode and Echo-Echo mode.
  • Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials.
  • Special transducer models are available for special application, including for coarse grain material and high temperature applications.
  • Probe-Zero function, Sound-Velocity-Calibration function
  • Two-Point Calibration function.
  • Three working modes: normal mode, scanmode and diff mode.
  • Coupling status indicator showing the coupling status.
  • Units: Metric and Imperial unit selectable.
  • Battery information indicates the rest capacity of the battery.
  • Auto sleep and auto power off function to conserve battery life.
  • USB2.0 communication port
  • Bluetooth support.
  • Size: 150mm×76mm×38mm
  • Weight: 295gColor TFT Display Coating Thickness Tester With Adjustable Backlight MT600Color TFT Display Coating Thickness Tester With Adjustable Backlight MT600Color TFT Display Coating Thickness Tester With Adjustable Backlight MT600

Transducer Technical Parameters

Model

Freq

MHz

Φ mm Measuring Range Lower limit Description
N02 2.5 14

3.0mm~300.0mm(In Steel)

40mm (in Gray Cast Iron HT200)

20mm for thick, highly attenuating, or highly scattering materials
N05 5 10

1mm~600.0mm

(In Steel)

Φ20mm×3.0mm

Normal Measurement

N05

/90°

5 10

1mm~600.0mm

(In Steel)

Φ20mm×3.0mm Normal Measurement
N07 7 6

0.65mm~200.0mm

(In Steel)

Φ15mm×2.0mm For thin pipe wall or small curvature pipe wall measurement
HT5 5 12

1~600mm

(In Steel)

30mm For high temperature (lower than 300℃) measurement.
P5EE 5 10

P-E: 2~600mm

E-E: 2.5~100mm

Φ20mm×3.0mm

Normal Measurement

and trough-coating thickness testing

Configuration

No Item Qty. Note
Standard Config. 1 Main body 1
2 Probe P5EE(5MHz) 1
3 Couplant 1
4 Instrument Case 1
5 Operating manual 1
6 Alkaline battery 2 AA size
7 Data Pro Software 1
8 USB Cable 1
Optional Config. 1 Probe N02 (2.5MHz) See Table1.1
2 Probe N05/90°(5MHz)
3 Probe N05 (5MHz)
4 Probe N07(7MHz)
5 Probe HT5(5MHz)

Operating Conditions

  • Operating Temperature: 0℃~+50℃;
  • Storage Temperature:-20℃~+70℃
  • Relative Humidity ≤80%;

The surrounding environment should avoid of vibration, strong magnetic field, corrosive medium and heavy dust.

Instrument Maintenance

When the thickness gauge appears some other abnormal phenomena, please do not dismantle or adjust any fixedly assembled parts. Fill in and present the warranty card to us. The warranty service can be carried on. Keep it away from vibration, strong magnetic field, corrosive medium, dumpiness and dust. Storage in ordinary temperature. With Original packing, transport is allowed on the third grade highway.
